Spraytech

SKU: ELGPS

Entry Level GPS System

Entry Level GPS System

£395.00
£395.00
Sale Contact Us for Price/Lead Time

all prices exclude VAT 20%

VAT & Shipping calculated at checkout.

A high-performance, multi-system dual-band navigation and positioning agriculture guidance system that supports GPS, Beidou, GLONASS, GALILEO and QZSS Satellite.


Dual Band: It comes with L1-L5 dual frequency positioning module, which makes positioning faster, more accurate and more reliable. Applications: Preload Farm applications, for example Filed bee Installation: Easy setup for your equipment with durable tractor mounts Always connected with built-in WiFi Always current with wireless updates of your software Operation: Simple-to-use with short-cut keys, LED power button, pinch-to-zoom Power: using vehicle ignition, accept
customisation
.

Product Parameters

Model No.

TG-96

Gerneral

Screen

9" capacitive touch screen

Resolution

800*480 px TFT 500nits Brightness

Processor

Cortex A53*4 1.3GHz

Memory

DDR3 1GB

NAND

16 GB

OS

Android 6.0

GNSS Module

Singal Frequency

GPS/QZSS :L1CA, L1C,L5
GLONASS: L1
BeiDou: B1C,B1I,B2a
GALILEO: E1,E5
SBAS: WAAS, EGNOS, MSAS, GAGAN, SDCM (L1)

Channels

136

Positioning accuracy

<1m CEP

Positioning Refresh Rate

MAX 20Hz

Time to first fix

Cold Start:<=28s Hot Start: <= 1s

Function

BT

BT 4.0

FM Transmitter

KT0806 76MHz~108MHz

Wifi

2.4 GHz frequency bands,B/ G /N

G-sensor

MC3236± 1.5g range 1 to 128 samples/sec

Other

Interface

Mini 5 pin USB, MicroSD Slot, Reset, Switch button

Interface (optional)

Serial Port, RS232, CAN, TTL

Speaker

1.5W / 8Ω

Waterproof Rate

/

Input

5V 2A

Battery

2500 mAH/3.7V
View full details
