This high-end NorthStar® NSQ SeriesTM Diaphragm Pump upgrades your sprayer with innovative components and engineering for superior spot or broadcast spraying performance and quick-connect convenience.  100% continuous duty with no cool down period

This NorthStar NSQ Sprayer Pump is packed with components that are designed to reduce wear and keep working, like a Honeywell MICRO SWITCHTM, a SantopreneTM diaphragm and a chemical-resistant fiberglass-reinforced polypropylene pump manifold.  The innovative smooth valve design provides faster primes.  It also has our unique pressure switch, designed to slowly cycle the pump to reduce switch and motor wear.  To conserve battery power, we gave it an automatic power switch that turns off when no flow is needed.  Compatible with Roundup® agricultural brand herbicide.

Specifications

Model Number:

NTE#:  2682271ST

Voltage:

12V DC

Maximum Flow Rate:

8.3 liters/minute (2.2 gallons/minute)

Pressure Switch:

Shut-Off:          Factory set at 70 PSI ± 2 PSI

                        (4.8 BAR ± 0.14 BAR)

Hysteresis:       Varies with outlet conditions

                        11 PSI ± 3 PSI at minimum on/off cycling

                        6 PSI ± 2 PSI at maximum on/off cycling

Wetted Materials:

Plastics:                     Polypropylene, Nylon (PA66)

Diaphragm:                Santoprene

Valves/Seals:              Viton

Check Valve Spring:    304 stainless steel

Liquid Temperature:

60° C (140° F) maximum

Prime:

Self-priming up to 3.05m (10-ft.)

Ports:

9.5mm (3/8in.) NPT

Weight:

2.27 kg (5 lbs)

Duty Rating:

Continuous (S1)

Protection Rating:

IPX1

Approvals:

CE compliant

Best-in-Class, Industrial-Grade Pump

No Cool Downs Required

Finally, a sprayer pump built to work as hard as you do without losing its cool. The industrial-grade NSQ Series on-demand pump is an engineering marvel, boasting an impressive 100% duty cycle. That means while the competition is waiting for their overworked, under designed sprayer to cool down, the NSQ Series pump isn't even working up a sweat.

Lasts 5 Times Longer

Building the best sprayer starts with using the best pump. With patent-pending DXS-3™ valves featuring chemical-resistant Viton, exclusive NSQ Series pumps provide faster priming, better performance and best of all, last up to 5 times longer than other brands.

Packed with Features

This NorthStar NSQ Sprayer Pump is packed with components that are designed to reduce wear and keep working, like a Honeywell MICRO SWITCH™, a Santoprene™ diaphragm and a chemical-resistant fiberglass-reinforced polypropylene pump manifold. The innovative smooth valve design provides faster primes. It also has our unique pressure switch, designed to slowly cycle the pump to reduce switch and motor wear. To conserve battery power, we gave it an automatic power switch that turns off when no flow is needed. When other pumps are in for repairs, the NSQ series is still on the job.
